Product Description
Isee Series
Specifications
| Isee系列参数 Panel Specification | ||||
| 产品型号 Part Number | Isee-5 | Isee-8 | ||
| 像素间距 Pixel Pitch | 5mm | 8.33mm | ||
| 像素构成 LED Configuration | SMD3in1 | SMD3in1 | ||
| 像素密度 Pixel Density | 40000dot/m2 | 14400dot/m2 | ||
| 通透率 Transparency | 70% | 81% | ||
| 箱体尺寸 Cabinet Size | 800X1400X60mm | 800X1400X60mm | ||
| 显示分辨率 Cabinet Resolution | 160X240dot | 96X144dot | ||
| 重量 Cabinet Weight | 40kg//Panel（glass） | 40kg//Panel（glass） | ||
| 防护等级 IP Rating ( front/back) | IP30 | IP30 | ||
| 亮度水平 Brightness | 4000-5500CD/m2 | 4000-5500CD/m2 | ||
| 可视角度 Viewing Angle (H/V) | 140°/140° | 140°/140° | ||
| 观看距离 Viewing Distance | ≥5m | ≥8m | ||
| 灰度等级 Gray Scale | 14bit | 14bit | ||
| 最大功率 Max.Power Consumption | 510W/Panel | 510W/Panel | ||
| 平均功率 Ave.Power Consumption | 170W/Panel | 170W/Panel | ||
| 刷新率 Refresh Rate | ≥1920Hz | ≥1920Hz | ||
| 使用环境 Environment | INDOOR | INDOOR | ||
| 控制方式 Control Mode | WIFI SD卡 脱机控制 | |||
| 输入电源 Operation Power | AC100~ 240V, 50/60Hz | |||
| 工作温度 Operating Temperature | - 10℃~+50℃ | |||
| 工作湿度 Operating Humidity | 10~90% RH | |||
| 工作寿命 Operating Life | ≥100,000hours | |||
